SECTION 2 - CONTROLS, INSTRUMENTS AND OPERATION
2ï104
Pick-up slip
If the pick-up speed drops 5% to 10% in relation to
the normal operating speed, the audible alarm will
sound and a message will appear in the message
window.
The message will remain as long as the pick-up slips
and for a minimum of 5 seconds.
The audible alarm will sound for a short period.
'Pick-up slip' warning 2 220
If the pick-up speed drops 10% to 15% in relation to
the normal operating speed, the audible alarm will
sound and a message will appear in the message
window.
The message will remain as long as the pick-up slips
and for a minimum of 5 seconds.
The audible alarm will sound continuously as long as
pick‐ up slip is detected.
Mistie Timeout
After a knotting cycle, there must be twine movement
on at least 2 knotters (on 4 knotter balers) or twine
movement on at least 4 knotters (on 6 knotter balers)
no twine movement for 15 stuffer strokes after
knotting before the mistie detection routine starts
again. This is to prevent false mistie indication due to
loose twine after the knotting cycle.
If there is no twine movement for some reason (i.e. a
mechanical link failure) within a certain time (>20
stuffer strokes) the mistie routine can not start up and this
is what the warning is saying.
As soon as you have the warning it means that the
mistie routine has not been started yet because there
is not sufficient twine movement on the knotters.
This warning is not coming up if the mistie detection
system is not working due to too many failures on the
mistie sensors (open, closed or 12v errors).
