SECTION 1 - GENERAL INFORMATION AND SAFETY
1ï18
Step on the service platform only, putting your feet on the
anti-slip strips and holding the guarding. Do not abuse the
steps or take a ride on the machine whilst is in motion.
IMPORTANT: On Rotor Cutter machines the step can be
lowered to reduce ground to step height. Always ensure
the steps are returned to the transport position shown
before driving off.
fixed in position for your own safety.
28
knotter fans will not operate if the guard is not firmly
closed.
The baler may be shipped with the knotter handrail (1)
and flags (2) in stowage.
Ensure the handrail (1) is secured in its correct
position with the supplied hardware, before
the knotter area. And the flags (2) are fitted
Ensure the baler is not running.
Climb onto the machine by using the service
Release safety latch (1).
Lift the knotter guard up to open.
Access to the fans is by the right hand side of the
baler. The operator must maintain a three point
contact at all times by having both hands at the
extreme right hand side of the top handrail.
The knotter fans operate when the baler is running
revs/min. Do not work in or around the fans
when the baler is running. Ensure the PTO is off,
engine stopped and start key removed from the
