SECTION 1 - GENERAL INFORMATION AND SAFETY
1ï20
• Monitor, tractor wire harness and battery
cable
• Operator's Manual
Close all guards and lock the pick-up in the transport
position.
The baler is equipped with four lifting eyes. Two on
the top front of the bale chamber and two underneath
the service platform which can be turned away to gain
When the baler has to be lifted for transport,
special attention must be paid to the attachment of
the sling hooks to the lifting eyes.
Use lifting components which are in line with the
European directive 98/37/EC and machinery
directive 2006/42/EC which can carry a weight of
minimum 11000 kg (24250 lbs).
have been removed, the bottom of
the service ladder is one of the lowest parts. Take
care not to damage the service ladder when moving
or putting the baler on a trailer. The baler hitch has to
be supported by means of wooden blocks. Do not use
the jack for this purpose.
