1 - TO THE OWNER
10
BUSINESS BAND RADIO READY (If Equipped)
Provisions for installing business band radios have
been provided for tractors equipped with the
Business Band Radio Option.
The antenna mast mounting threaded spud (1) and
antenna lead wire (if equipped) are factory installed
in the roof of the cab approximately 2 inches (50
mm) under the cab top. The spud is already wired
with RF-58/U cable.
A locating dimple (2) in the cab top marks the
location for drilling the hole for the antenna mast.
NOTE: The antenna mast for a one-quarter (1/4)
wave UHF business band radio must be purchased
locally and must be compatible with an Antenna
Specialist Model K-794 low profile antenna mount.
See Antenna Specialist at www.antenna.com for
additional information.
RH02H173
1. ANTENNA MAST MOUNTING THREADED SPUD
1
MK00E007
2. LOCATING DIMPLE
2
