Engine-Engineandcrankcase
Engine-Install-9Litertractors
Steiger350
1.Attachloadrotor4130liftingbaleorequivalentto
anoverheadhoistandthetwoengineliftingbrack-
ets.Installisomounts,liftengineandsetintotractor
frame.
NOTICE:Theengineliftingbracketsareforverticallifting
only.Anyliftingdevicethatisnotverticallyinlinewiththe
liftingbracketscandamagetheenginerockerarmcoveror
causebracketfailure
RCPH10FWD022BBC1
2.Installfrontenginemountbracket.T orquethelower
enginemounttoframebolts(1)to90-107N·m(66
-79lbft).TorquetheISOmountnut(2)to160-220
N·m(118-162lbft).
RCPH10FWD021BBC2
3.Installrearretainingstrapstobothsides.Torque
boltsto125-150N·m(92-111lbft)..
RCPH10FWD020BBC3
4748821326/02/2013
10.1[10.001]/8
