Engine-Engineandcrankcase
4.Connectdriveshafttodrivecoupler.Torquethebolts
to95-108N·m(70-80lbft).
RCPH10FWD018BBC4
5.Connectfuelreturnline.
NOTE:Removeplugandcapfromhoseandtting.
RCPH10FWD017BBC5
6.Installupperradiatorhose(1)andrighthandairto
airtube(2).Removesupportstrap(3).
RCPH10FWD016BBC6
4748821326/02/2013
10.1[10.001]/9
