STEP 33
MK99J013
Remove the lock nut, bolt and washers from the front
engine mount.
STEP 34
MK99J030
Remove the lock nut, large flat washer, bolt and small
flat washer from the left side (shown) and right side
rear engine mounts.
STEP 35
MK99J040
To remove the engine, lift the engine until the oil pan
will clear the front frame engine mount crossmember.
Move the engine forward out of the tractor.
