STEP 45
MK99J177
Install the heater supply hose (1) and return hose (2)
on the engine and tighten the hose clamps.
STEP 46
MK99J025
Use the M8 x 20 bolt and flat washer to install the
heater hose and battery cable bracket on the right
side motor mount. Tighten the bolt to specifications.
STEP 47
MK99J021
Install the battery cable, starter switch power supply
wire and alternator cable on the starter solenoid.
STEP 48
MK99J022
Install the starter switch wire on the starter solenoid.
STEP 49
MK99J026
Install the exciter wire on the alternator.
STEP 50
MK99J027
Install the battery wire on the alternator.
1
2
