STEP 57
MK98G023
Turn the valve lever counterclockwise to open the fuel
shut-off valve on the tank.
STEP 58
MK99J018
Use the M8 x 20 bolt, washer and nut to install the
A/C suction and dryer hoses on the hose bracket.
STEP 59
MK99J020
Lubricate new o-rings with clean A/C compressor oil
and install the o-rings on the hose ends. Install and
tighten the suction (1) and discharge (2) hoses on
the A/C compressor.
STEP 60
MK99J023
Install the high pressure switch wire connector on the
engine wire harness.
STEP 61
MK99J011
Install the hood support/air cleaner bracket over the
top of the engine.
2
1
