STEP 20
MD02A218
Lift the rubber coupler and spray with denatured
alcohol to loosen the rubber from the tube.
STEP 21
MD02A217
Loosen the clamp and remove the air tube assembly
from the turbo air inlet and the tractor.
STEP 22
MD02A219
Remove the heater supply tube from the engine.
Install a cap on the engine port and a plug in the tube
end.
STEP 23
MD02A220
Remove the two heater return tube clamps from the
engine.
STEP 24
MD02A221
Remove the heater return tube from the filter head.
Install a cap on the filter head adapter and a plug in
the tube end.
STEP 25
MD02A222
Turn the tube 90° clockwise and remove from
between the oil filter and engine. Secure the tube
away from the engine.
