STEP 26
MD02A223
Remove the four bolts and washers. Remove the air
tube mount and wire harness bracket from the motor
mount.
NOTE: Two bolts and the wire harness bracket are
on the opposite side.
STEP 27
MD02A224
Remove the deaeration hose and fuel hose clamps
from the engine.
STEP 28
MD02A226
Shut off the fuel tank valve.
STEP 29
MD02A225
Remove the clamp and remove the fuel hose from
the fuel pump. Install a plug in the hose end and a
cap on the fuel pump adapter.
STEP 30
MD02A228
Remove the fuel supply hose. Install a plug in the
hose end and a cap on the fuel pump adapter.
STEP 31
MD02A229
Remove the ground strap from the starter.
