STEP 55
MD02A233
Install the starter wire harness (1) in the double
clamp (2) and install the double clamp and top clamp
(3) on the engine bracket.
STEP 56
MD02A232
Install the starter switch wire on the starter solenoid.
STEP 57
MD02A252
Install the cover on the solenoid and use the nut to
secure the cover.
STEP 58
MD02A230
Install the positive battery cable and wires.
STEP 59
MD02A229
Install the negative cable and grounding strap.
STEP 60
MD02A228
Install and tighten the fuel supply hose on the fuel
pump.
1
2
3
