STANDARD SCREW A TORQUE SPECIFICATIONS
Correct screw identification
Zinc bichromate
Phosphate
Diameter x
thread size
Grade 8.8
Key
Torque
Nm lb.ft
Two-part hydraulic connector
(to SAE J518 specifications)
PDG0321
Components assembled by
screws and bolts
SCREW
BOLT
PDG0322
M5 x 0.8
M6 x 1
M8 x 1.5
M10 x 1.5
M12 x 1.75
M14 x 2
M16 x 2
M18 x 2.5
M20 x 2.5
M22 x 2.5
M24 x 3
M27 x 3
M30 x 3.5
4
5
6
8
10
12
14
14
17
17
-
-
-
8
10
13
17
19
22
24
27
30
32
36
41
46
5.5
9
22.5
45
70
100
170
250
350
500
600
900
1200
5.5
9
22.5
45
80
120
200
300
400
600
700
1000
1400
4.1
6.7
16.6
33.2
51.6
73.8
125.5
184.5
258.3
369
442.8
664.2
885.6
4.1
6.7
16.6
33.2
59
88.6
147.6
221.4
295.2
442.8
516.6
738
1033.2
Grade 10.9
M5 x 0.8
M6 x 1
M8 x 1.5
M10 x 1.5
M12 x 1.75
M14 x 2
M16 x 2
M18 x 2.5
M20 x 2.5
M22 x 2.5
M24 x 3
M27 x 3
M30 x 3.5
4
5
6
8
10
12
14
14
17
17
-
-
-
8
10
13
17
19
22
24
27
30
32
36
41
46
75
12.5
35
60
100
170
250
350
500
700
900
1200
1700
75
12.5
35
70
120
200
300
400
600
800
1000
1400
1900
5.6
9.3
25.8
44.3
73.8
125.5
184.5
258.3
369
516.6
664.2
885.6
1254.6
5.6
9.3
25.8
51.6
88.6
147.6
221.4
295.2
442.8
442.8
738
1033.6
1402.2
PDG0320
Steel grade Steel grade
