10.Removethe3hosebands(1).
SMIL13CEX1234AB7
11.Prepareawasteoilcan(1).
•
Draintheengineoilbeforedisconnectingtheengine
oilhose.
SMIL13CEX1235AB8
12.Useawrench[36mm]todisconnectthe2engineoil
remotehoses(1).
•
Marktheengineandhosessothattheconnectors
matchatthetimeofassembly.
•
Installcapsorplugstotheengineandhosestopre-
ventanyentryofwater,dustordirt.
•
Cleantheengineandhosesbysprayingthemwith
apartscleanertopreventscratchesandpreventdirt
fromaccumulatingontheconnectors.
SMIL13CEX1236AB9
13.Useawrench[8mm]toremovethe1nut(1),and
thenremovethewiring(2)fromthestartermotor.
SMIL13CEX1238AB10
