14.Useawrenchtoremovethe1nut(1),andthenre-
movethestartermotorwiring(2).
SMIL13CEX1239AB11
15.Removethehoseband(1),andthendisconnectthe
fuelhose(2).
•
Installcapsorplugstotheengineandhosetopre-
ventanyentryofwater,dustordirt.
SMIL13CEX1240AB12
16.Removethehoseband(1),andthendisconnectthe
fuelhose(2).
•
Installcapsorplugstotheengineandhosestopre-
ventanyentryofwater,dustordirt.
SMIL13CEX1241AB13
17.Useawrench[13mm]toremovethe2bolts(1),and
thendisconnecttheconnectorbracket(2).
