Engine-Engineandcrankcase
18.Useawrench[13mm]toremovethehoseband(1)
fromthebracket,andthendisconnecttheconnectors
(2).
•
Wraptheremovedconnectorsinplasticaftertying
themtogether.
SMIL13CEX1243AB15
19.Loosenthehoseband(1),andthendisconnectthe
heaterhose(2).
•
Installcapsorplugstotheengineandhosetopre-
ventanyentryofwater,dustordirt.
SMIL13CEX1244AB16
20.Loosenthehoseband(1),andthendisconnectthe
heaterhose(2).
•
Installcapsorplugstotheengineandhosetopre-
ventanyentryofwater,dustordirt.
SMIL13CEX1245AB17
21.Useawrench[7mm]toloosenthehoseband(1),
andthendisconnecttheradiatorhose(2).
•
Usecapstocoverthelinesandhosestopreventany
entryofwater,dustordirt.
SMIL13CEX1246AB18
