Engine-Engineandcrankcase
22.Useawrench[8mm]toloosenthehoseband(1),
andthendisconnecttheairhose(2).
•
Usecapstocoverthelinesandhosestopreventany
entryofwater,dustordirt.
SMIL13CEX1247AB19
23.Useawrench[7mm]toloosenthehoseband(1),
andthendisconnecttheairhose(2).
•
Usecapstocoverthelineandhosetopreventany
entryofwater,dustordirt.
SMIL13CEX1248AB20
24.Disconnecttheconnectors(1)fromthealternator.
SMIL13CEX1249AB21
25.Useawrench[10mm]toremovethenut(1),andthen
removethealternatorwiring(2).
SMIL13CEX1250AB22
4809034402/01/2017
10.1[10.001]/17
