2 - DESCRIPTION OF THE MACHINE
1 - Front frame
2 -
Rearframe
3 - Articulatedjoint
4 - Front and rearforks
5 - Front and rear drum
6 - Engine
7 - Hydraulicgeneratoroftravel
8 - Tandem hydraulic generator of vibration and power steering
9 - Hydraulicoilcooler
1 0 - Motor air filter
11 - Exhaust
12 - Fueltank
13- Hydraulicoiltank
14 - Sprinklingwatertankfrontand rear
1 5 - Platform
16- Hood
17 - Sprinkling pump
18 - Sprinkling of the drums
19- Scrapersofthedrums
20- Battery
21 - ProtecliveframeROPS
22 - Travel hydraulic motor
23 - Vibration hydraulic motor
