6. DIAGNOSTIC OPERATION
To start the diagnostic program
ECR enters the diagnostic mode by the following operation.
1 Turn the mode key to PGM.
2 Input “99990000” and “ST(SUB TOTAL)”.
Upon the above operation ECR prints the following and issues a receipt.
* Note that the test mode will not boot if once a receipt has been issued in the REG/RF/X/Z mode.
In this case, remove the battery and perform the above operation again.
FEED
029 C
7 8 9
4 5 6
1 2 3
0 011 012
028 023
027 022
021 017
020 016
019 015
018 014
013 013
026
025
024
d1d2d3d4: Version No.
d5: Destination PAD
0: domestic
1: general export (ADD2)
2: US/Canada
d6: 0: tax spec
1: no tax spec
“-”: overseas
07: 0: domestic
“-”: overseas
* “#” is not printed for US and Canada.
6-1. Content of the Test
1 Displaying the Key Code ......................... Press any key other than the ten keys and clear key.
2 Displaying the Switch Condition .............. Press the clear key, or change the status of switches.
3 Printing, Display and Drawer test ............ One digit number + “ST(SUB TOTAL)” key
6-2. Displaying the Key Code
Press any key other than the ten keys and clear key to dipslay the hard key code as shown below.
(Display) 019
2000-00-00
00-00#0001
-d1d2d3d4--d5d6d7
To Next Page
