— 35 —
PCR262/CE160
Price
Code
RankN Code No. Parts Name Specification
Q'ty
OSS WHC Canada
Item
FEED PLATE/S 1E270 RJE500737-1 1 1 1 X
AC/C PLATE/S 2E270 RJE500737-2 1 1 1 X
X/FOR/DATE TIME PLATE/S 30E270 RJE500737-30 1 1 1 X
-/ERR.CORR PLATE/S 4E270 RJE500737-4 1 1 1 X
PLU PLATE/S 5E270 RJE500737-5 1 1 1 X
#/DEPT SHIFT PLATE/S 6E270 RJE500737-6 1 1 1 X
%/CLK# PLATE/S 7E270 RJE500737-7 1 1 1 X
RA/T/S1 PLATE/S 31E270 RJE500737-31 1 1 1 X
PO/T/S2 PLATE/S 32E270 RJE500737-32 1 1 1 X
CH PLATE/S 10E270 RJE500737-10 1 1 1 X
CHK/NS PLATE/S 11E270 RJE500737-11 1 1 1 X
SUB TOTAL PLATE/S 12E270 RJE500737-12 1 1 1 X
MD/ST PLATE/S 13E270 RJE500737-13 1 1 1 X
9/4 PLATE/S 33E270 RJE500737-33 1 1 1 X
10/5 PLATE/S 34E270 RJE500737-34 1 1 1 X
+/NONTAX/6/1 PLATE/S 14E270 RJE500738-14 1 1 1 X
-/TAXABLE/7/2 PLATE/S 15E270 RJE500738-15 1 1 1 X
X/3/8 PLATE/L 16E270 RJE500738-16 1 1 1 X
CA/AMT TEND PLATE/L 4E270 RJE500738-4 1 1 1 X
3. POWER CORD BLOCK
N 30 1012 6964 CORD/POWER ME301 1 1 1
AM
C
CONNECTOR CE2 2 2 2 X
4. UPPER CASE BLOCK
N 31 1018 5145 CASE/UPPER E264 RJE501317-001V01 1 1 1
BC
C
N 32 1018 5144 MOUNT/PR E264 RJE501321-001V01 1 1 1
AC
C
33 1090 5329 PRINTER M-42V-009-060MA 1 1 1
CB
A
N 34 1018 5148 C-SW ASSY RJE501346*001V01 1 1 1
AQ
C
N 35 1018 5147 KNOB/C-SW E264 RJE501323-002V01 1 1 1
AB
C
N 1019 1100 HOLDER/PCB E264 RJE501367-001V01 1 1 1
AA
C
N 1019 1108 BAT CABLE SUB ASSY RJE501366*001V01 1 1 1
AA
C
36 6322 4499 SPRING/BAT A-G55 A42606-1 1 1 1
AA
C
37 6000 6091 SPRING/BAT G67 A43656-1 1 1 1
AA
C
38 6001 0862 SPRING/BAT B-1G513 P408-1 1 1 1
AB
C
39 6001 0871 SPRING/BAT B-2G513 P409-1 1 1 1
AA
C
SCREW S-WLPT-3X8ZC 6 6 6 X
SHEET/INS E264 RJE501394-1 1 1 1 X
SCREW S-WLPT-3X12ZC 3 3 3 X
SCREW S-BDST-3X8ZC 1 1 1 X
FILLER/C-SW E264 RJE501396-1 1 1 1 X
N 40 1018 5137 COVER/B E264 RJE501320-001V01 1 1 1
AA
C
N 41 1018 5138 PULLY/WIND E264 RJE500691-002V01 1 1 1
AE
C
42 1012 6974 SPOOL/PAPER HOLDER E270 RJE500720-001V01 1 1 1
AB
C
N 43 1018 5139 BOARD/DP E264C OSS RJE501318-003V01 1
AG
C
N 43 1018 5188 BOARD/DP E264C WHC RJE501318-004V01 1 1
AG
C
N 44 1018 5140 COVER/PR E264 RJE501319-001V01 1 1 1
AJ
C
N 45 1018 5141 CUTTER/PAPER E264 E441364-003V01 1 1 1
AB
C
SCREW S-BDST-3X8ZC 2 2 2 X
