Casio 130CR Service Manual

— 32 —
130CR
Price
Code
UK Europe USA
Item
Other Countries
Plug Type
N RankSpecificationParts NameCode No.
Q'ty
Europe UK AustraliaGermany
AC/C PLATE/S 2E270 RJE500737-2 1 1 1 1 1 1 1 X
-/ERR.CORR PLATE/S 4E270 RJE500737-4 1 1 1 1 1 1 1 X
PLU PLATE/S 5E270 RJE500737-5 1 1 1 1 1 1 1 X
CH PLATE/S 10E270 RJE500737-10 1 1 1 1 1 1 1 X
X/3/8 PLATE/L 16E270 RJE500738-16 1 1 1 1 1 1 1 X
CA/AMT TEND PLATE/L 4E270 RJE500738-4 1 1 1 1 1 1 1 X
MR/RA PLATE/S 35E270 RJE500737-35 1 1 1 1 1 1 1 X
P0 PLATE/S 36E270 RJE500737-36 1 1 1 1 1 1 1 X
% PLATE/S 18E270 RJE500737-18 1 1 1 1 1 1 1 X
#/NS PLATE/S 19E270 RJE500737-19 1 1 1 1 1 1 1 X
X/DATE TIME PLATE/S2 37E270 RJE500737-37 1 1 1 1 1 1 1 X
CHK PLATE/S 3E270 RJE500737-3 1 1 1 1 1 1 1 X
SUB TOTAL PLATE/L 5E270 RJE500738-5 1 1 1 1 1 1 1 X
+ 1 PLATE/L 8E270 RJE500738-8 1 1 1 1 1 1 1 X
- 2 PLATE/L 9E270 RJE500738-9 1 1 1 1 1 1 1 X
X 3 PLATE/L 10E270 RJE500738-10 1 1 1 1 1 1 1 X
/ 4 PLATE/L 11E270 RJE500738-11 1 1 1 1 1 1 1 X
3. POWER CORD BLOCK
30 3701 0242 CORD/POWER MP5004 1 1 BO C
30 6221 4802 CORD/POWER M2511 1 1 1 BC C
30 1016 4361 CORD/POWER X-AU10S3 1 BO C
30 1002 3027 CORD/POWER PS204-A 1 AR C
CONNECTOR CE2 2 2 2 2 2 2 2 X
4. UPPER CASE BLOCK
N 31 1018 5145 CASE/UPPER E264 RJE501317-001V01 1 1 1 1 1 1 1 BC C
N 32 1018 5144 MOUNT/PR E264 RJE501321-001V01 1 1 1 1 1 1 1 AC C
33 1090 5725 PRINTER M-42V-009-040 1 1 1 1 1 1 1 CH A
N 34 1018 5148 C-SW ASSY RJE501346*001V01 1 1 1 1 1 1 1 AQ C
N 35 1018 5147 KNOB/C-SW E264 RJE501323-002V01 1 1 1 1 1 1 1 AB C
N 1019 1100 HOLDER/PCB E264 RJE501367-001V01 1 1 1 1 1 1 1 AA C
N 1019 1108 BAT CABLE SUB ASSY RJE501366*001V01 1 1 1 1 1 1 1 AA C
36 6322 4499 SPRING/BAT A-G55 A42606-1 1 1 1 1 1 1 1 AA C
37 6000 6091 SPRING/BAT G67 A43656-1 1 1 1 1 1 1 1 AA C
38 6001 0862 SPRING/BAT B-1G513 P408-1 1 1 1 1 1 1 1 AB C
39 6001 0871 SPRING/BAT B-2G513 P409-1 1 1 1 1 1 1 1 AA C
SCREW S-WLPT-3X8ZC 6 6 6 8 8 8 8 X
SHEET/INS E264 RJE501394-001V01 1 1 1 1 1 1 1 X
SCREW S-WLPT-3X12ZC 3 3 3 3 3 3 3 X
SCREW S-BDST-3X8ZC 1 1 1 1 1 1 1 X
FILLER/C-SW E264 RJE501396-001V01 1 1 1 1 1 1 1 X
N 40 1018 5137 COVER/B E264 RJE501320-001V01 1 1 1 1 1 1 1 AA C
N 41 1018 5138 PULLY/WIND E264 RJE500691-002V01 1 1 1 1 1 1 1 AE C
42 1012 6974 SPOOL/PAPER HOLDER E270 RJE500720-001V01 1 1 1 1 1 1 1 AB C
N 43 1018 5200 BOARD/DP E264B RJE501318-002V01 1 1 1 1 1 1 1 AG C
N 44 1018 5140 COVER/PR E264 RJE501319-001V01 1 1 1 1 1 1 1 AJ C
N 45 1018 5141 CUTTER/PAPER E264 E441364-003V01 1 1 1 1 1 1 1 AB C
SCREW S-PAST-4X8ZC 1 1 1 1 1 1 1 X
WASHER 4 ZMC-3 1 1 1 1 1 1 1 X
SCREW S-BDST-3X8ZC 2 2 2 2 2 2 2 X
