DL-1329A(S type) U.S.A.
N Item Code No. Parts Name Specification Qt'y
Price
code
Rank
1 10127601 CASE/MAIN RJE500670-001V01 1 BC X
N 2 10127602 PLATE/T.C ED21-16 RJE500672-001V01 1C
3 55000878 ROLLER/DELRIN DR-19B2 2 AP B
4 10259120 LEVER ASSY/HOOK RJE502182*001V01 1 AA C
5 10127603 AXIS/HOOK LEVER ED21 RJE500674-001V01 1 AA C
6 10080393 SPRING/LOCK ED16 RJE500007-001V01 1 AA C
7 62466522 SPRING/PRESS ED14 E412137-1 1 AA C
8 62466529 RUBBER/ED14 E412136-1 5 AD C
SCREW 4X25 ZMC-3 1 X
NUT 4 ZMC-3 1 X
NUT 6 ZMC-3 2 X
WASHER 11.5X6.5X0.8 2 X
SCREW 3X8 ZMC-3 4 X
SCREW 3X20 ZMC-3 2 X
9 10087969 SOLENOID SUB ASSY RJE500126*002V01 1 AW B
10 10127599 DRAWER/ED21-16 RJE500671-001V01 1 AZ C
11 10106265 PLATE/PARTITION S-BK RJE500214-001V01 3 AA C
N 12 10190958 BILL HOLDER SUB ASSY RJE501337*001V01 1 C
13 10079063 SPRING/BILL HOLDER ED16 E441357-1 4 AA C
14 55000878 ROLLER/DELRIN DR-19B2 2 AP B
NUT 6 ZMC-3 2 X
15 54400287 RIVETS/COLD HEADED 5X26 1 AA C
16 55801452 CS FIX CTSW-5 1 AA C
17 10140789 CASE/COIN E266 RJE500212-001V02 1 AG C
18 10109076 SEPARATER/COIN E266 RJE500213-001V01 4 AK C
19 10120527 LOCK/CYLINDER CL-16C 1 AS C
SCREW 3X8 ZMC-3 3 X
20 COVER/TOP E270-16 RJE500753-002V02 1 X
SCREW 3X6 ZMC-3 3 X
21 LABEL/DL-1329A E341256-47 1 X
