Heart Rate Measurement Screen
A Movement time from measurement start
B Current heart rate
C Target HR zone value
Current time screen
A Current time
B Movement time from measurement start
Altitude screen
A Altitude of current location
B Current heart rate
C [DIFF RESET] (Altitude Differential Reset)
and the altitude differential
D Movement time from measurement start
Barometric pressure screen
A Current barometric pressure
B Current temperature
C Barometric pressure graph
D Current heart rate
E Movement time from measurement start
Bearing screen
A Current bearing
B Current bearing angle
C Current heart rate
D Movement time from measurement start
Almanac screen
A Date of measurement
B Measurement day Moon age
C Measurement day sunrise time
D Measurement day sunset time
E Movement time from measurement start
Altitude navigation screen
A Shows the current altitude at the scale
location
B Currently displayed checkpoints
C Altitude set for the currently displayed
checkpoint
D Altitude difference between current
altitude and checkpoint
E Movement time from measurement start
F Current heart rate
●
A pointer ( ) to the right of the scale along
the left of the screen also indicates the
altitude differential between the checkpoint
and current altitude. The appearance of the
pointer changes as described below.
This
pointer:
Means this:
Altitude differential of +100 m (Or:
+100 ft) or more
Altitude differential within -100 to
100 m (Or: -100 to 100 ft)
Altitude differential of -100 m (Or:
-100 ft) or more
●
For information about advanced navigation
settings, see the information below.
l
Specifying Checkpoints Along a Training
Course (Altitude Navigation)
Note
●
Holding down (D) for at least two
seconds switches the checkpoint
display.
Watch Operation Guide 3554
77
To Next Page
