Casio AP-200

– 28 –
1 AP-200_DI_120V
2 AP-200_DI_230V
3 AP-200_EU
4 AP-200_UK
5 AP-200_US
1 2 3 4 5
VR601 10273791 VARIABLE RESISTOR F-09KGH-CASIO-1 1 1 1 1 1 AJ C
N D607-610 10276977 CHIP DIODE L1SS400T1G 4 4 4 4 4 AA
X
N D601-606 10294401 LED LT2P71-81-M1-70495 6 6 6 6 6 AB
X
N IC601,602 10294403 IC TC74VHC164F(EL.K.F 2 2 2 2 2 AN
X
SW601-607 10228658 TACT SWITCH THVV502GAA 7 7 7 7 7 AA C
N 17 10294090 PCB ASSY/CNA2 TK-RJM508391*001 1 1 1 1 1 CB C
J601,602 10171449 CONNECTOR JY-6360*04-070 2 2 2 2 2 AE C Phone
j
ack
L601,602 10231919 COMMON MODE COIL RB53-856396NP 2 2 2 2 2 AA
X
N 18 10294095 PANEL ASSY/CONSOL
E
TK-RJM508277*001 1 1 1 1 1 C
X
C
N 19 10294353 BRACKET RJM508338-001V01 2 2 2 2 2 AB C
N 20 58614294 NUT USN-4015 2 2 2 2 2 AB
21 10269829 SPEAKER C12J02 2 2 2 2 2 A
X
C
N 22 10294355 NET RJM508336-001V01 2 2 2 2 2 AL
X
23 10212713 HARNESS EH-2P-46-M404 1 1 1 1 1 AA C for L.SP
N 24 10298363 HARNESS EH-2P-68-M333 1 1 1 1 1 AH C for R.SP
N 25 10294098 PCB ASSY/CNA3 TK-RJM508392*001 1 1 1 1 1 B
X
C
CN608 10207671 CONNECTO
R
HDC-052SP-02 1 1 1 1 1 AK C
L605 10206672 COIL R2318-RB53856396N
P
1 1 1 1 1 AA
X
L604 10206680 COIL R2318-RB53856397N
P
1 1 1 1 1 AA
X
N 26 10169597 BRACKET RJM504221-001V01 1 1 1 1 1 AA
X
N 27 10294354 BRACKET RJM508332-001V01 1 1 1 1 1 AF
X
N 28 10294099 PCB ASSY/CNA5 TK-RJM508394*001 1 1 1 1 1 BV C
J604 10208247 CONNECTO
R
DJ-0702B*019 1 1 1 1 1 AB
X
DC JACK
L606 10231920 COMMON MODE COI
L
RB53-856397NP 1 1 1 1 1 AA
X
N 29 10294356 BRACKET RJM508431-001V01 1 1 1 1 1 AL
X
N 30 10298364 HARNESS SMP-4P-41-M333 1 1 1 1 1 AM C For Pedal
31 10212699 FERRITE CORE K5ARP40X6.5X1
2
1 1 1 1 1 AS C For FFC
N 32 10204256 FERRITE CORE TRCN16-13 2 2 2 2 2 AW C
N 33 10294070 COVER ASSY/KEY TK-RJM508274*001 1 1 1 1 1 DO C
34 10211850 GEAR RJM505897-001V01 2 2 2 2 2 AA C
N 35 10294073 BOARD ASSY/TOP TK-RJM508275*001 1 1 1 1 1 DK C
Ke
y
board UNI
T
N 36 10298122 KEY UNIT TK-RJM506362*003 1 1 1 1 1 EF A
37 10204304 CHASSIS/KEY RJM505515-001V01 1 1 1 1 1 B
X
C
38 10135317 BLACK KEY RJM502797-001V01 36 36 36 36 36 AC C
39 10135426 WHITE KEY/CEGB RJM502862-001V01 7 7 7 7 7 AT C 4pcs-1set
40 10135427 WHITE KEY/DFA RJM502863-001V01 7 7 7 7 7 AQ C 3pcs-1set
41 10135428 WHITE KEY/B RJM502794-001V01 1 1 1 1 1 AG C
42 10135429 WHITE KEY/SA RJM502795-001V01 1 1 1 1 1 AJ C
43 10135430 WHITE KEY/SC RJM502796-001V01 1 1 1 1 1 AJ C
44 10208265 HAMMER ASSY/W1 TK-RJM506035*001 13 13 13 13 13 AF C
45 10208266 HAMMER ASSY/W2 TK-RJM506036*001 13 13 13 13 13 AF C
46 10208267 HAMMER ASSY/W3 TK-RJM506037*001 13 13 13 13 13 AF C
47 10208269 HAMMER ASSY/W4 TK-RJM506038*001 13 13 13 13 13 AF C
48 10208275 HAMMER ASSY/B1 TK-RJM506039*001 9 9 9 9 9 AE C
49 10208281 HAMMER ASSY/B2 TK-RJM506040*001 9 9 9 9 9 AE C
50 10208286 HAMMER ASSY/B3 TK-RJM506041*001 9 9 9 9 9 AE C
51 10208290 HAMMER ASSY/B4 TK-RJM506042*001 9 9 9 9 9 AE C
52 37195442 FFC N30315B1B05-UL289
6
1 1 1 1 1 AO C
53 10133656 RUBBER/CONTACT/AG RJM502920-001V01 7 7 7 7 7 AK C
54 10133635 RUBBER/CONTACT/GC RJM502921-001V01 1 1 1 1 1 AG C
N 55 10294093 CUSHION/HAMMER TK-RJM507910*001 1 1 1 1 1 CG C
N 56 10294094 PCB ASSY/KEY TK-RJM506061*003 1 1 1 1 1 CU C
Specification
Q'T
Y
Price
Code
N Item Parts No. Parts Code R Remarks
