Casio AP-200

– 27 –
1 AP-200_DI_120V
2 AP-200_DI_230V
3 AP-200_EU
4 AP-200_UK
5 AP-200_US
1 2 3 4 5
MAIN PCB
N 1 10294100 PCB ASSY/MAIN TK-RJM508412*001 1 1 1 1 1 DO A
X1 10133372 CRYSTAL OSCILLATOR SMD-49-12M 1 1 1 1 1 AI B
Q2 10202670 TRANSISTOR KTA2014-GR-RTK/P 1 1 1 1 1 AA C
Q1 22592764 TRANSISTOR 2SB1188T100Q 1 1 1 1 1 AB C
L13,16,17 10122963 COIL BLM21AG102SN1D 3 3 3 3 3 AC C
L8,11,12,20 10095204 CHIP BEAD CORE BLM18AG102SN1D 4 4 4 4 4 AA C
N IC6 10284634 LSI NAND128W3A2BN6E 1 1 1 1 1 BI C
N IC2 10284633 LSI MD56V62162J75TA03A 1 1 1 1 1 BC C
IC7 10262261 LSI MB82D01181E60LPBNE 1 1 1 1 1 BC C
IC11 10253886 LSI UPD65942GA-Y299EUA 1 1 1 1 1 AX C
IC5 10255468 LSI MB91F036PFF-GE1 1 1 1 1 1 CB C
IC9 10258396 IC TC74VHC541FT(EL.K) 1 1 1 1 1 AE C
IC8 10123002 IC TC74VHC174FT(EL) 1 1 1 1 1 AD C
IC1 10241413 IC R1151N001C-TR-F 1 1 1 1 1 AE C
IC10 10256338 IC CS4351-CZZR 1 1 1 1 1 AS C
N F8 10132152 EMI FILTER NFW31SP106X1E4L 1 1 1 1 1 AI C
F3,4,5,9,10,11 10122976 NETWORK/ R-C EZASTB63ABJ 6 6 6 6 6 AA C
F6,7 10122975 NETWORK/ R-C EZASSB516BJ 2 2 2 2 2 AA C
PSA1 PCB
N 2 10294096 PCB ASSY/PSA1 TK-RJM508382*001 1 1 1 1 1 CW B
N E202 10292899 RELAY G5PA-28-MCDC5V
(
PF
)
1 1 1 1 1 BC C
IC201 10203081 IC LA4636-E 1 1 1 1 1 AV C
L204 10231919 COMMON MODE COI
L
RB53-856396NP 1 1 1 1 1 AA
X
L201,202,203 10231920 COMMON MODE COI
L
RB53-856397NP 3 3 3 3 3 AA
X
N D208 10294392 DIODE EDZTE6112B 1 1 1 1 1 AB
X
N D203 10294393 DIODE EDZTE618.2B 1 1 1 1 1 AB
X
N D202,205,212 10276977 CHIP DIODE L1SS400T1G 3 3 3 3 3 AA
X
N D206 10210387 DIODE RSX101VA-30T
R
1 1 1 1 1 AA
X
N D201 10294394 DIODE SK34A 1 1 1 1 1 AD
X
N D213 10294395 PHOTO COUPLER PC900V0NIPXF 1 1 1 1 1 A
X
X
N IC206 10294396 IC NJM2123M
(
TE1
)
1 1 1 1 1 AT
X
IC202 10201503 I.C PQ1CG21H2FZH 1 1 1 1 1 AO
X
L205 10208248 COIL R187-860400NP 1 1 1 1 1 AC
X
Q205 69409403 CHIP TRANSISTOR 2SA1576AT106
R
1 1 1 1 1 AA
X
Q201,204,206,
208,212,213,
215,216,
217,218
69300298 CHIP TRANSISTOR 2SC4081T106R 10 10 10 10 10 AA X
Q202 10213764 TRANSISTOR 2SD2351T106W 1 1 1 1 1 AA
X
MAIN CASE UNI
T
N 3 10294101 CASE ASSY/MAIN TK-RJM508276*001 1 1 1 1 1 EC C
N 4 10294102 BOARD-ASSY/FRONT TK-RJM508281*001 1 1 1 1 1 C
X
C
N 5 10294103 PCB ASSY/CNA4 TK-RJM508393*001 1 1 1 1 1 BV C
N 6 10294091 SIDEUNIT/R TK-RJM508279*001 1 1 1 1 1 BQ C
7 69245260 BUTTON/POWER M340318-001 1 1 1 1 1 AA C
N 8 10294362 SIDE BLOCK/R RJM508326-001V01 1 1 1 1 1 AQ C
9 10229392 POWER SWITCH SDDL1PCHL011 1 1 1 1 1 AS C
N 10 10298365 HARNESS EH-2P-131-M33
3
1 1 1 1 1 AK C To Power SW
N 11 10294363 BRACKET/R RJM508404-001V01 2 2 2 2 2 AD
X
N 12 10294085 SIDE BLOCK/L TK-RJM508278*001 1 1 1 1 1 CV C
13 10052232 KNOB/ROTARY M341402-001 1 1 1 1 1 AE C
N 14 10294361 SIDE BLOCK/L RJM508325-001V01 1 1 1 1 1 AR C
15 10281445 RUBBER KEY RJM505783-002V02 1 1 1 1 1 AD C
N 16 10294089 PCB ASSY/CNA1 TK-RJM508390*001 1 1 1 1 1 CG C
N Item Parts No. Parts Code
Q'T
Y
Specification
Price
Code
R Remarks
