— 4 —
DISASSEMBLY INSTRUCTIONS
1. Disassembling top board
1-1. Remove 8 screws on the rear.
1-2. Slide the top board towards the rear.
The top board will be free from catches on the case.
1-3. Lift the top board.
2. Disassembling keyboard cover
2-1. Slide the keyboard cover to open fully.
2-2. Passing the gear into the opening on each rack, lift the
keyboard cover.
