8
Part II
Channel Message
4 Receive Channel
The channel number of the channel message received by each part is shown in the table under "1.3.2 Instrument Part Block".
5 Send Channel
Basically, the MIDI channel of the channel message sent when the Instrument is played coincides with the MIDI channel
of the part being played. Note, however, that the MIDI channel of the performance information that corresponds to the
keyboard main part is the Keyboard Channel setting value.
6 Note Off
Format
Send
Sent when something is played on the keyboard or when auto accompaniment is used. For keyboard play, the key number
range is changed in accordance with the octave shift function.
Receive
Received by Instrument parts corresponding to MIDI. The velocity value is ignored. A part that is turned off by the Part
Enable Parameter value explained under "24.3 Part Parameter" is not received.
7Note On
Format
Send
Sent when something is played on the keyboard. The key number range is changed in accordance with the octave shift
function.
Receive
Received by Instrument parts corresponding to MIDI. The velocity value is ignored. A part that is turned off by the Part
Enable Parameter value explained under "24.3 Part Parameter" is not received.
Message Format: 8nH kkH vvH
9nH kkH 00H (receive only)
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Send 40H
Receive Ignored
Message Format: 9nH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Velocity
