— 19 —
NOTE
TEST mode
menu
Check for
sending and
receptivity
Check for
sending and
receptivity
TEST mode
menu
End
Press
AC/ON
button
while pressing
F6
and
ab/c
but-
tons.
Press
5
button.
Press
1
button.
Press
2
button.
Press
EXE
button.
Press
1
button.
Press
EXE
button.
Press
AC/ON
button.
Take the steps as
same as the end of
5. OPERATION
CHECK to end this
check.
Press
AC/ON
button
while pressing
F6
and
ab/c
but-
tons.
Press
5
button.
Press
1
button.
Press
1
button.
Press
EXE
button.
Press
2
button.
Press
EXE
button.
Press
AC/ON
button.
Take the steps as
same as the end of
5. OPERATION
CHECK to end this
check.
Turn off both units (A and B unit), then connect them using the cable SB-60 or SB-62. Perform STEP 1 ~ 4
described in 5. OPERATION CHECK before this check.
STEP
STEP 4
of
5.OP-
ERA-
TION
CHECK
1
2
3
4
5
6
7
8
9
10
OPERATION
DISPLAY
A unit
B unit
DISPLAY
TRANSMIT Check
1. COM Check
2.
VCCI Spec Test
0. Self
1. Send
2. Receive
WAITING
RECEIVING
COM OK
0. Self
1. Send
2. Receive
SENDING
COM END
0. Self
1. Send
2. Receive
TRANSMIT Check
1. COM Check
2.
VCCI Spec Test
0. Self
1. Send
2. Receive
SENDING
COM END
0. Self
1. Send
2. Receive
WAITING
RECEIVING
COM OK
0. Self
1. Send
2. Receive
OPERATION
ZX935 TEST MODE
1. Cnt
2. LCD
3. KEY
4. DET
5. TRS
6. ROM
7. RAM
8. CYC
0. Rst
ZX935 TEST MODE
1. Cnt
2. LCD
3. KEY
4. DET
5. TRS
6. ROM
7. RAM
8. CYC
0. Rst
ZX935 TEST MODE
1. Cnt
2. LCD
3. KEY
4. DET
5. TRS
6. ROM
7. RAM
8. CYC
0. Rst
ZX935 TEST MODE
1. Cnt
2. LCD
3. KEY
4. DET
5. TRS
6. ROM
7. RAM
8. CYC
0. Rst
6. DATA TRANSFER CHECK
