12. PARTS LIST
N Item Code No. Parts Name Specification Q R
ZX933-1 ASS'Y
LSI3 2012 3192 LSI TC55257DFL-7085V 1 B
LSI4 2012 3185 LSI LC3564SM-70 1 B
N LSI2 2012 5645 LSI MBM29LV800B-Z935 1 B
Q2 2250 1281 Chip transistor 2SA1179M5, M6, M7-TB 1 C
IC1 2114 4683 CMOS-IC TC74HC4066AFS(EL) 1 C
IC2 2105 2737 CMOS-IC RH5RL50AA-T1 1 C
IC6 2105 2968 CMOS-IC RH5RE43AA-T1 1 C
THR1 2755 0147 Thermister 104HT 1 X
VR1 3122 3227 Chip variable resister CVR-32A-503SX2 1 X
X1 2590 1967 Ceramic oscillator CSTC4.30MG-TC 1 C
ZX933-2 ASS'Y
1 6416 9441 Battery spring A-Z933 A441557A-1 1 X
2 6416 9450 Battery spring B-Z933 A441558-1 1 X
3 3501 6538 Mini jack HSJ1169-012010 1 C
Q1 2259 0959 Chip digital transistor DTC114YKT-146 1 C
LCD UNIT
4 3335 6216 LCD CD1052-TS 1 B
5 6416 9370 LCD holder Z933 A341010-1 1 C
6 5610 9050 Heat seal C-Z933 A340956-1 1 B
7 5610 9060 Heat seal S-Z933 A341018-1 1 B
LSI5 6417 3441 COF3015-F1 sub ass'y C340532A*2 1 B
LSI6 6416 3211 COF3016-F1 sub ass'y C340533A*1 1 B
PCB UNIT
N 8 6420 7250 Z933-2 ASS'Y A240572A*2 HK 1 B
N 9 6420 2300 Z933-1 ASS'Y A140379Q*4 HK 1 B
10 6417 3430 LCD UNIT A240603B*2 HK 1 B
11 6408 0210 PC joiner L370 A413642-1 1 B
COMPONENTS
12 6416 9340 Key contact rubber Z933 A240567-1 1 C
N 13 6420 2330 Hard case Z935AE A240568-3 1 C
14 6416 9500 Battery holder A441594-1 1 X
15 6416 9380 Display plate Z933 A341011-1 1 C
16 6390 0432 Cap V332 A310765B-1 1 C
17 6413 5080 Button E-L392 A313257-3 1 C
18 6413 5090 Button F-L392 A313257-4 1 C
N 19 6420 5330 Button B-Z935 A340110-3 1 C
20 6413 6000 Button H-L392 A340256-1 1 C
21 6419 5130 Button A-Z934 A240072-4 1 C
N 22 6420 5310 Button B-Z935 A211316-10 1 C
23 6413 5011 Button C-L392 A340111A-1 1 C
N 24 6420 5340 Button D-Z935 A340123-3 1 C
N 25 6420 5320 Button G-Z935 A313257-8 1 C
N 26 6420 2320 Upper case Z935AE A140373-7 1 X
27 6417 3450 Badge label Z933 A441676-1 1 C
N 28 6420 2340 Battery cover Z935AE A240903-3 1 C
29 6408 0110 Battery spring B-L370 A410113-3 2 X
30 6408 0120 Battery spring L370 A412218-2 1 X
31 6419 9840 Rubber key Z934 A341594-1 1 C
N 32 6420 2350 Lock spring Z935AE A341016-3 1 C
N 33 6420 2362 Lower case Z935AY A140374B-8 1 X
34 6417 3520 Spring H-Z933 A441675-1 1 C
Parts prices will be informed separately by Parts Price List.
Notes: N – New parts Essential
Q – Quantity used per unit Stock recommended
R – Rank Others
No stock recommended
R – A :
B :
C :
X :
R – A :
B :
C :
X :
— 28 —
