7.20 Reverb Send Level (5BH)
Message Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the reverb send of the corresponding part.
7.21 Chorus Send Level (5DH)
Message Format: BnH 5DH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the chorus send of the corresponding part.
7.22 Delay Send Level (5EH)
Message Format: BnH 5EH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the delay send of the corresponding part.
7.23 RPN (64H,65H)
Message Format: BnH 64H llH (LSB)
BnH 65H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
7.23.1 Pitch Bend Sensitivity
Message Format: BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(00H - 18H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Transmit Sent when calling Registration. (CT-S400/CT-S410)
Sent when the bend range is changed. (CT-S400/CT-S410)
Receive Receipt changes bend range of the corresponding part.
12
