Receive Receipt changes the part volume.
7.6 Pan (0AH)
Message Format: BnH 0AH vvH
n: MIDI Channel Number
vv: Value(Note1)
Note1: For information about the relationship between setting values and send/receive values, see “13.5 Pan Setting Value
Table” in “IV Setting Values and Send/Receive Values”.
Receive Receipt changes the pan of the corresponding part.
7.7 Expression Controller (0BH)
Message Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the expression value.
7.8 Damper pedal (sustain) (40H)
Message Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when a pedal that has a sustain function is operated.
Receive Receipt performs an operation equivalent to a sustain pedal operation.
Timbre Type Specific Operation This op eration differs in accordance with the Timbre Type (see
“About the Timbre Type” in “8 Program Change”) setting.
• Timbre Type: Melody,Hex Layer
Sustain off/on control is performed in accordance with the value of the received message. For
information about the relationship between setting values and send/receive values, see the “13.2
Off/On Setting Value Table” in “IV Setting Values and Send/Receive Values”.
• Timbre Type: Piano
Continuous control of the following is performed in accordance with the value of the received
message.
– Piano note decay rate
For information about the relationship between setting values and send/receive values, see “13.3
Sustain Pedal Setting Value Table” in “IV Setting Values and Send/Receive Values.”
8
