7.22 Delay Send Level (5EH)
Message Format: BnH 5EH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when the knob is operated by setting. Sent when Delay type or GM tone is selected.
Receive Receipt changes the delay send of the corresp onding part.
7.23 RPN (64H,65H)
Message Format: BnH 64H llH (LSB)
BnH 65H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
7.23.1 Pitch Bend Sensitivity
Message Format: BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(00H - 18H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Transmit Sent when calling Registration. Sent when the bend range is changed.
Receive Receipt changes bend range of the corresponding part.
7.23.2 Channel Fine Tuning
Message Format: BnH 64H 01H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Transmit Sent when calling Registration.
Receive Receipt changes the fine tune of the corresp onding part.
14
