CTK-2200
– 11 –
A-2. Place the main unit with the keys facing up.
A-3. Lift the main panel unit and turn it over.
NOTE: The main panel unit is connected to the lower case unit with the lead wires and FFCs.
Use caution when turn over the main panel unit.
Main panel unit
Lead wires
(Left speaker)
Lead wires
(Right speaker)
Lead wires
(Batteries)
FFC
(M800-KYA2)
