CTK-2200
– 18 –
F-3. Remove ve rubber contact strips.
NOTE: One rubber contact strip differs in length.
Rubber contact strips
This rubber contact strip differs
from the others in length.
<How To Install Rubber Contact Strips>
• Lightly insert the tip of a rubber contact strip into the
PCB. Pull the tip from the back of the PCB and install
it using a tool such as tweezers. Do not forcibly pull it.
To Next Page
