CTK-2200
– 19 –
DIAGNOSTIC PROGRAM

PREPARATION
(1) Connect the AC adaptor.
NOTE: The AC adaptor (AD-E95100L) for the CTK-2200_DI and CTK-2200_UK is sold separately
and does not come with the product. If you do not have the AC adaptor, use six AA-size dry
batteries with enough capacity.
NOTE: “AC ADAPTOR CHECK” cannot be performed unless the AC adaptor is connected.
(2) Turn the main volume to the maximum.
(3) Have a PC and a USB cable ready.
NOTE: “USB CHECK” cannot be performed without a PC and a USB cable.
Operating System: Windows
®
XP (SP2 or later) *
1
Windows Vista
®
*
2
Windows 7
®
*
3
Mac OS
®
X (10.3.9, 10.4.11, 10.5.8 or later, 10.6.6 or later)
*1: Windows XP Home Edition/Windows XP Professional (32 bit)
*2: Windows Vista (32 bit)
*3: Windows 7 (32 bit, 64 bit)

HOW TO START THE DIAGNOSTIC PROGRAM
(1) Hold down the “0”, “1” and “2” buttons at the same time, to turn the power ON.
NOTE: Be sure to turn OFF the power when the test is nished.
(2) Release the “0”, “1” and “2” buttons.
(3) After the diagnostic program is launched, the test mode screen appears.

Casio CTK-2200 Specifications

General

Keyboard number of keys	61
MIDI-keyboard number of keys	- keys
Product color	Black, Grey
Maximum polyphony (notes)	48
Music memory capacity (songs)	110
Interface	USB
Power requirements	9V
Power source type	AC

Weight and Dimensions

Depth	307 mm
Width	946 mm
Height	92 mm
Weight	3400 g
