Casio CTK-2200 User Manual

CTK-2200
– 21 –
A-2. Press the button in the order indicated in the illustration.
NOTE: You cannot cancel this check procedure mid-way.
<If the result passes>
The conrmation chord sounds and “1:SW00XX” is displayed on the LCD with “XX” indicating the
corresponding button number in the illustration.
<If the result fails>
If there is a button failure or the buttons are pressed in a wrong sequence, an error tone sounds
and the button number which you pressed will be displayed on the LCD.
1F
03
00
02
0D 0A 0B 0E 0C 0F
SW OK!
161514
191817
1211
1B
1A
10
01
04 05 06 07 1C
1E 1D 09 08
START

Casio CTK-2200 Specifications

General

Keyboard number of keys	61
MIDI-keyboard number of keys	- keys
Product color	Black, Grey
Maximum polyphony (notes)	48
Music memory capacity (songs)	110
Interface	USB
Power requirements	9V
Power source type	AC

Weight and Dimensions

Depth	307 mm
Width	946 mm
Height	92 mm
Weight	3400 g
