CTK-2200
– 28 –
1: CTK-2200_DI
2: CTK-2200_EU
3: CTK-2200_UK
4: CTK-2200_US
1234
MAIN PCB
N 1 10401017 PCB UNIT/MAIN TK-RJM511249*001 1111 AMDA1
J1 10206815 JACK/PEDAL JY-6314*01-030 1111 B
CN8 10236624 CONNECTOR/USB UBR24-4K5G00 1111 C
L11 10193074 COIL DLW21HN181SQ2L 1111 X
D4 10009218 DIODE 1SS400TE61 1111 X
IC5 10211950 IC NJM2068M-D(TE1) 1111 X
N IC6 10398240 IC XC6402FV36PR-G 1111 X
N LSI2 10396644 MEMORY MX29LV160DBTI-70G 1111 C
X1 10375016 RESONATOR 7V48080006 1111 X
N Q12,Q13 10399706 TRANSISTOR DSC500100L 2222 X
SUB PCB
N 2 10401018 PCB UNIT/POWER & AMP TK-RJM511239*001 1111 BPSA1
L103,L104 10231919 COIL RB53-856396NP 2222 X
L102,L105,
L106
10231920 COIL RB53-856397NP 3333 X
J102 35015103 JACK/DC HEC3110-01-010 1111 A
J103 10305218 JACK/PHONE JY-6316B*01-070 1111 B
J104 10305131 JACK/AUDIO IN ST-3529B 1111 B
IC103,IC104 10206677 IC NJM2068D-D 2222 C
N IC101 10370338 IC TA8227APG-D12-H-T 1111 X
IC301 10222381 LSI ST7066U-0A-QG 1111 C
Q106 10206835 TRANSISTOR KTA1046-Y-U/P 1111 X
VR301 69304870 VARIABLE RESISTOR EVND8AA03B53 1111 XContrast for LCD
D103,D104,
D301-D308
23901820 DIODE 1SS355TE-17 10 10 10 10 X
D101,D102 10261170 DIODE SRT14-A2 2222 X
D105 23603102 DIODE UDZSTE-175.1B 1111 X
TH301 10245365 THERMISTOR TSM1A103J34D3RZ 1111 X
N
Q102,Q104,
Q108,Q109
10399706 TRANSISTOR DSC500100L 4444 X
Q105 10217742 TRANSISTOR KTA1270-Y-AT/P 1111 X
Q101 10206675 TRANSISTOR KTA1273-Y-AT/P 1111 X
KEYBOARD PCB
3 10401014 PCB UNIT/KYA TK-RJM508609*003 1111 CKYA1/KYA2
D801-D830,
D832
10301580 DIODE LM1MA142WAT1G 31 31 31 31 X
PANEL UNIT
N4 10402407 DISPLAY PLATE RJM511072-001V02 1111 X
5 10199714 KNOB/SLIDE RJM503803-002V01 1111 X
N 6 10394574 CASE/PANEL RJM511042-001V01 1111 X
7 69276630 FABRIC TAPE/8X15 M440832-1 2222 X
8 69270510 SLIDE CONTACT/8D CSB-08D 1111 X
8-1 10417025 FABRIC TAPE/SL RJM511833-001V01 1111 X
N9 10402514 SHEET/for fireproofing RJM511371-001V02 1111 X
N 10 10405127 LCD ZAS-TY012725DN00 1111 X
11 10301465 RUBBER CONNECTOR/for LCD RJM508539-001V01 2222 X
N 12 10400577 RUBBER BUTTON/A RJM511051-001V01
1111 X
N 13 10400579 RUBBER BUTTON/B RJM511052-001V01 1111 X
N 14 10400581 RUBBER BUTTON/C RJM511053-001V01 1111 X
N 15 10400583 RUBBER BUTTON/D RJM511054-001V01 1111 X
N 16 10400585 RUBBER BUTTON/E RJM511055-001V01 1111 X
N 17 10400589 RUBBER BUTTON/F RJM511056-001V01 1111 X
N 18 10400591 RUBBER BUTTON/G RJM511057-001V01 1111 X
N RemarksSpecificationParts NameCode No.Item R
Q'ty
Price
Code
