Casio EX-843

– 10 –
V-R200 / VER.1
Rear
19181715
16
20 21
15 DC jack Connect the AC adaptor.
16 Drawer connecting cable Cable for connecting to the drawer.
17 USB port Connect the USB device. *1
18 LAN port Connects with external devices via a hub. *1
19 COM3 port Connect device such as printer, etc. *1
20 COM2 port Connect device such as printer, etc. *1
21 COM1 port Connect device such as printer, etc. *1
*1: Use the recommended product. For detailed information, contact your sales outlet.
Front
22
23 24
22 Sheet cover Connector cover
23 Serial console connector Connector for development (not used )
24 microUSB port Connector for development (not used )
