Casio EX-843

V-R200 / VER.1
– 57 –
H. Other Parts
Supplementary explanation
• For the parts other than the replaced parts, reuse the original ones.
H-1. REAR CASE BLOCK
SPEAKER
Screw (S7) 2
Screw (S6)
CASE/REAR
COVER/BOOT
BLIND/DALLAS
Screw (S9) 2
H-2. CASE ASSY/FRONT
LENS/LED
Screw (S10) 3
PCB ASSY/E843-E61
CASE ASSY/FRONT
