A. Replacing the Main PCB
Supplementary explanation
When the main PCB is replaced with a spare part one.
• Since an OS is already installed on the spare part main PCB, update the OS to an appropriate
version as required.
Refer to: Diagnostic operation
2. UPDATING the OS
• Write the serial number.
Refer to: Diagnostic operation
1-6. Checking and Registering the Serial Number
A-1. Removal of the DISPLAY-ASSY
(1) Undo two screws.
Screw (S1)
(2) Remove the DISPLAY-ASSY.
To Next Page
