V-R200 / VER.1
– 34 –
Y
Important
• Please note that the product on this manual may appear to be different from the actual one according
to the changes such as engineering design change.
• In order to prevent static electricity and avoid leaving grease from the hand, wear conductive gloves,
fi nger cots, or anti-static band when assembling/disassembling the product.
• Do not use metal tweezers. Be sure to use plastic tweezers with fl at tips.
(Anti-static tweezers are recommended)
• When replacing the MCR, refer to “V-R7000/V-R7100 Installation Manual”.
• The disassembly procedure explained here is based on the model “V-R7100-BD” that is equipped with
Dallas key.
MCR
Dallas key
To Next Page
