Casio EX-843

V-R200 / VER.1
– 39 –
A-4. Undo four screws and remove the CHASSIS/HNG.
Screw (S2) 4
CHASSIS/HNG
Note on reassembling
0
Fix the lead wires of the battery with tape.
Tape
Note on reassembling
V-R200-BD (Dallas key built in model)
0
Fix the ferrite core with double-sided tape, and then fi x its lead wires and the lead wires of the battery together
with tape.
CUSHION/DLS Tape
