— 22 —
14. Remove one screw and then the Lens plate.
15. Remove the lens unit.
■ Removing the strobe unit
16. Remove the strobe unit and then the battery frame.
17. Remove one screw and then the strobe unit.
Screw
Screw
Lens plate
