Casio EX-Z60 - Parts List

— 33 —
PARTS LIST
Silver Black Red
N 1 10236142 CASE/LCD RJK508673-001V01
111
AG C
N 2 10237128 LCD UNIT TK-RJK508768*001
111
CZ A
N 3 10236168 TAPE/LCD RJK508718-001V01
111
AB C
N 4 10236151 FPC/KEY HKW1568-010010
111
AV C
N 5 10236054 FRAME ASSY/BATTERY RJK508665*001V01
111
AS C
N 6 10236199 CASE/TOP RJK508676-001V01
100
AN C
N 6 10236190 CASE/TOP RJK508676-002V01
010
AI C
N 6 10236191 CASE/TOP RJK508676-003V01
001
AI C
N 7 10236201 BUTTON/SHUTTER RJK508678-001V01
111
AG C
N 8 10236200 BUTTON/POWER RJK508677-001V01
111
AF C
N 9 10236202 SPRING/SW RJK508674-001V01
111
AA C
N 10 10236203 SPACER/SHUTTER RJK508735-001V01
111
AB C
N 11 10236143 BASE/SW RJK508690-001V01
111
AB X
N 12 10236144 TAPE/SW RJK508706-001V01
111
AB X
N 13 10237121
CASE ASSY/STROBE
TK-RJK508765*001
111
BF C
14 10200800
SPRING/BATTERY
RJK507791-001V01
111
AA C
N 15 10236064 WASHER STRAP RJK508707-001V01
111
AB X
N 16 10236062 BRACKET/L RJK508671-001V01
111
AE X
N 17 10237127 PCB ASSY/MAIN TK-RJK508934*001
111
DM A
N 18 10236149 MIC OBG415L42C2-R815
111
AH C
N 19 10237130 LENS UNIT RJK508771*001 TK 1 1 1 AB A*1
N 20 10236061 LENS RING RJK508670-001V01
111
AE A *2
N 21 10237118 ASSY/BATTERY TK-RJK508766*001
100
BM C
N 21 10237119 ASSY/BATTERY TK-RJK508766*002
010
BM C
N 21 10237120 ASSY/BATTERY TK-RJK508766*003
001
BM C
22 10210305 SPEAKER DS-1325ACKX-25
111
AJ C
23 10210279 NET/SPEAKER RJK507880-001V01
111
AF C
N 24 10236181 COVER/BATTERY RJK508680-001V01 100AIC
N 24 10236186 COVER/BATTERY RJK508680-002V01 010AIC
N 24 10236188 COVER/BATTERY RJK508680-003V01 001AIC
N 25 10236148 STROBE UNIT XEST-K815
111
BV C
N 26 10237122
PANEL ASSY/FRONT
TK-RJK508762*001
100
BY C
N 26 10237123
PANEL ASSY/FRONT
TK-RJK508762*002
010
BZ C
N 26 10237124
PANEL ASSY/FRONT
TK-RJK508762*003
001
BY C
N 27 10236107 CAM RING RJK508639-001V01
101
AK C
N 27 10236114 CAM RING RJK508639-002V01
010
AK C
N 28 10236128 TAPE/CR RJK508700-001V01
222
AB C
N 29 10236080 STRAP BOARD RJK508638-001V01
111
AB X
N 30 10236078 SIDE PANEL/LA RJK508636-001V01
100
AE C
N 30 10236081 SIDE PANEL/LB RJK508636-002V01
010
AF C
N 30 10236126 SIDE PANEL/LC RJK508636-003V01
001
AF C
N 31 10236079 SIDE PANEL/RA RJK508637-001V01
100
AF C
N 31 10236082 SIDE PANEL/RB RJK508637-002V01
010
AG C
N 31 10236091 SIDE PANEL/RC RJK508637-003V01
001
AG C
N 32 10236063 PLATE/DISPLAY RJK508675-001V01
101
AI C
N New parts
*1 Floppy disk is bundled.
*2 Not included in the Lens unit.
*3 AC cord is not equipped.
N Item
Parts
Code
Parts Name Specification R Remark
Price
Code
Overs
