Casio Exilim EX-ZR700 User Manual

20
Quick Start Basics
Back Lamp Operation
• The information in parentheses in the above table shows the lamp status while the
camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s
battery (NP-130) without removing it from the camera. You also can charge the
battery using an optionally available charger unit (BC-130L). Never use any other
type of charger device. Attempting to use a different charger can result in
unexpected accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards.
Use of an inferior device or a device that is not up to standard can cause
malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you.
Even in the case of a commercially available computer, certain USB port
specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give
the battery time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the USB-AC adaptor into an outlet that is further away from
the TV or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging.
Use of any other type of devices may result in improper charging.
Lamp Status Description
Lit Red,
(Lit/Flashing Amber)
Charging
Flashing Red
Abnormal ambient temperature,
charging taking abnormally long, or
battery problem (page 173)
Off, (Lit Green) Charging complete
Back lamp

Casio Exilim EX-ZR700 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	18 x
Combined zoom	286.9 x
Focal length range	4.5 - 81 mm
Maximum aperture number	7
Minimum aperture number	3.5
Lens structure (elements/groups)	11/10
Maximum focal length (35mm film equiv)	450 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.04 - 0.5 m
Auto Mode focusing range (wide)	0.04 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.4 - 3.5 m
Flash recharging time	5 s
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution	640 x 1440 pixels
Display resolution (numeric)	921600 pixels
USB version	2.0
Product color	Red
Scene modes	-
White balance	Auto, Daylight, Manual, Shade, Tungsten
Self-timer delay	2, 10 s
Battery type	NP-130
Battery life (max)	6.25 h
Battery life (CIPA standard)	470 shots
Cables included	USB

Weight and Dimensions

Depth	30.7 mm
Width	107.4 mm
Height	60 mm
Weight	182 g
Weight (including battery)	222 g
