43
Snapshot Tutorial
NOTE
An Auto Macro feature detects how far the subject is from the lens and
automatically selects either Macro Focus or Auto Focus accordingly.
Use of the flash together with Macro Focus can cause the light of the flash to
become blocked, which may result in unwanted lens shadows in your image.
Whenever you perform an optical zoom operation while shooting with Auto Focus,
Macro Focus, or Manual Focus, a value will appear on the monitor screen to tell
you the focus range, as shown below. Note that the focus range is displayed
including the Auto Macro range only when shooting with Auto Focus.
Example: oo
* cm - 9
* oo is the actual focusing range value.
The operations assigned to the [4] and [6] keys with the “L/R Key” setting (page
93) are disabled while Manual Focus is selected as the focus mode.
The “Focus” setting is always fixed at “AF” (Auto Focus) whenever “Face
Detection” is being used. If you want to change the “Focus” setting, first select “Off”
for “Face Detection”.
Using Focus Lock
“Focus lock” is a technique you can use when you want to
compose an image in which the subject you want to focus
on is not within the focus frame in the center of the
screen.
To use focus lock, select “U Spot” or “O Tracking” for
the Auto Focus area (page 99).
1. Align the monitor screen’s focus frame with
the subject you want to focus on and then half-
press the shutter button.
2. Keeping the shutter button half-pressed
(which maintains the focus setting), move the
camera to compose the image.
When “O Tracking” is selected as the Auto Focus
area, the focus frame will move automatically and
follow the subject.
3. When you are ready to shoot the image, press the shutter button the
rest of the way down.
NOTE
Focus lock also locks exposure (AE).
Subject to be focused on
Focus frame

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio Exilim EX-ZR700 and is the answer not in the manual?

Casio Exilim EX-ZR700 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedEXIF, JPG
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom18 x
Combined zoom286.9 x
Focal length range4.5 - 81 mm
Maximum aperture number7
Minimum aperture number3.5
Lens structure (elements/groups)11/10
Maximum focal length (35mm film equiv)450 mm
Minimum focal length (35mm film equiv)25 mm
Focus adjustmentAuto
Auto focusing (AF) modesSpot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)0.04 - 0.5 m
Auto Mode focusing range (wide)0.04 - ∞ m
Light meteringCentre-weighted, Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Flash off, Flash on, Red-eye reduction
Flash range (tele)1.5 - 2.1 m
Flash range (wide)0.4 - 3.5 m
Flash recharging time5 s
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution640 x 1440 pixels
Display resolution (numeric)921600 pixels
USB version2.0
Product colorRed
Scene modes-
White balanceAuto, Daylight, Manual, Shade, Tungsten
Self-timer delay2, 10 s
Battery typeNP-130
Battery life (max)6.25 h
Battery life (CIPA standard)470 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth30.7 mm
Width107.4 mm
Height60 mm
Weight182 g
Weight (including battery)222 g
