Casio Exilim EX-ZR700 User Manual

48
Snapshot Tutorial
4. Press the shutter button to shoot.
• For information about Flash Range, see page 193.
IMPORTANT!
• Even if you have the Control Panel setting configure for flash, the flash will not fire
unless the flash unit is open.
• When not using flash, press down on the flash unit until it locks into place with a
click.
• Foreign matter on the flash window can react with the light of the flash, producing
some smoke and abnormal odor. Though this does not indicate malfunction, oil
from your fingers and other foreign matter when left on the flash window can
become difficult to clean off later. Because of this, you should make it a regular
habit to wipe the window clean regularly with a soft, dry cloth.
NOTE
• Take care so your fingers and the strap do not block the flash.
• The desired effect may not be obtained when the subject is too far away or too
close.
• Flash charging time (page 193) depends on operating conditions (battery
condition, ambient temperature, etc.).
• Shooting with flash turned off when lighting is dim results in a slow shutter speed,
which can cause image blur due to camera movement. Under such conditions,
secure the camera with a tripod, etc.
• With red eye reduction, the flash is fired automatically in accordance with
exposure. It does not fire in areas where lighting is bright.
• The presence of outdoor sunlight, fluorescent lighting, or some other light source
can cause abnormal image colors.
• Select ? (Flash Off) for the flash setting when shooting in areas where flash
photography is prohibited.
• The flash > (Auto Flash) and ¥ (Red Eye Reduction) flash modes are not
supported while A, S, or M is selected for the recording mode. If you want the flash
to fire, select < (Flash On) as the flash mode.
Back lamp
Flashes orange while the flash is charging to
indicate that image recording is disabled.
• You will not be able to take another flash
snapshot until the lamp stops flashing orange,
which indicates that charging is complete.
< indicates the flash will fire.

Casio Exilim EX-ZR700 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	18 x
Combined zoom	286.9 x
Focal length range	4.5 - 81 mm
Maximum aperture number	7
Minimum aperture number	3.5
Lens structure (elements/groups)	11/10
Maximum focal length (35mm film equiv)	450 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.04 - 0.5 m
Auto Mode focusing range (wide)	0.04 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.4 - 3.5 m
Flash recharging time	5 s
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution	640 x 1440 pixels
Display resolution (numeric)	921600 pixels
USB version	2.0
Product color	Red
Scene modes	-
White balance	Auto, Daylight, Manual, Shade, Tungsten
Self-timer delay	2, 10 s
Battery type	NP-130
Battery life (max)	6.25 h
Battery life (CIPA standard)	470 shots
Cables included	USB

Weight and Dimensions

Depth	30.7 mm
Width	107.4 mm
Height	60 mm
Weight	182 g
Weight (including battery)	222 g
