Casio Exilim EX-ZR700 User Manual

66
Recording Movies
IMPORTANT!
• Spending a long time using movie recording will cause the camera to become
slightly warm to the touch. This is normal and does not indicate malfunction.
• Shooting movies for long periods in areas where temperature is relatively high can
cause digital noise (dots of light) to appear in the movie image. A rise in the
camera’s internal temperature also may force movie recording to stop
automatically. If this happens, stop recording and allow the camera to cool down,
which should cause normal operation to resume.
• Using the camera’s built-in memory or certain types of memory cards can slow
down processing speed. Whenever possible use an Ultra High-Speed Type
memory card. Note, however, that not all operations can be guaranteed even if an
Ultra High-Speed Type memory card is used. Certain movie quality settings can
result in too much time being required to record data, which can result in breaks in
the image and/or audio during playback. If this happens, the Y will turn yellow on
the monitor screen.
NOTE
• Zoom operations are supported during movie recording (page 50). Zoom is
disabled during high speed movie recording. To use zoom for high speed movie
recording, perform the zoom operation before you press [0] (Movie) to start
recording.
• Both Single SR Zoom (page 53) and Multi SR Zoom (page 54) are disabled during
movie recording.
• The effects of camera movement in an image become more pronounced when you
shoot close up or with a large zoom factor. Because of this, use of a tripod is
recommended under these conditions.
• Except for High Speed Movie, Continuous AF (page 101) is performed during
movie recording while “AF” (Auto Focus) or “Macro” is selected for the “Focus”
setting.
• Face Detection is disabled during normal FHD and STD, and high speed movie
recording. Face Detection is enabled when shooting movies with Premium Auto
Pro (FHD and STD).
• The following functions do not support movie recording.
Blurred Background, All-In-Focus Macro, Triple Shot, Multi SR Zoom, some BEST
SHOT scenes
• The A, S, and M recording modes are not supported when shooting a movie, or
when using the “Prerecord (Movie)” and “For YouTube” BEST SHOT scenes. In
these cases, the recording mode is always P (Program Auto).

Casio Exilim EX-ZR700 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	18 x
Combined zoom	286.9 x
Focal length range	4.5 - 81 mm
Maximum aperture number	7
Minimum aperture number	3.5
Lens structure (elements/groups)	11/10
Maximum focal length (35mm film equiv)	450 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.04 - 0.5 m
Auto Mode focusing range (wide)	0.04 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.4 - 3.5 m
Flash recharging time	5 s
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution	640 x 1440 pixels
Display resolution (numeric)	921600 pixels
USB version	2.0
Product color	Red
Scene modes	-
White balance	Auto, Daylight, Manual, Shade, Tungsten
Self-timer delay	2, 10 s
Battery type	NP-130
Battery life (max)	6.25 h
Battery life (CIPA standard)	470 shots
Cables included	USB

Weight and Dimensions

Depth	30.7 mm
Width	107.4 mm
Height	60 mm
Weight	182 g
Weight (including battery)	222 g
