2-15
Drawing and Editing Objects
Note
• You can specify a line segment, line, ray, or one side of a polygon as the axis of refl ection.
• If you select only part of an object before performing step 3 of the above procedure, only
the selected part will be refl ected. If you selected side BC of the triangle in step 2, perform
the rest of the steps starting from step 3 would refl ect side BC only as shown below.
u To translate an object by specifi ed values
1. Draw the object you want to translate. Here, we will use a triangle.
2. Perform the following operation: 5(Transform) – 2:Translation.
• This displays the Translation screen.
3. Input vector format values to specify the distance of parallel translation.
• The value in line 1 is the translation distance along the X-axis, while the value in line 2 is
the distance along the Y-axis.
//
To Next Page
