20060601
2-16
Drawing and Editing Objects
4. After the values are the way you want, press w.
• This performs parallel translation of the object by the distance specifi ed by the values
you input in step 3.
Note
If you select only part of an object before performing step 2 of the above procedure, only the
selected part will be translated.
u To translate an object using an existing vector
1. Draw the object you want to translate. Here, we will use a triangle. Next, draw the vector
you want to use for parallel translation.
2. Perform the following operation: 5(Transform) – 3:Trans(Sel Vec).
• This will cause the message “Select Vector” to appear.
3. Move the pointer close to the vector you want to use for the parallel translation.
• Move the pointer towards the vector until marks appears on it.
To Next Page
